China Lithium Battery Manufacturer Custom-Made HY 0144117 360mAh 3.7V Rechargeable Super thin Battery

$1.69
In stock
SKU
HY 0144117 360mAh 3.7V

FOB Price: US $1.2 - 1.5 / Ampere
Min.Order Quantity: 1000 Ampere
Please contact us for the order !

size :T1*W44*L117MM
Type: Li-ion polymer battery
Weight:7g
Capacity:360mAh
Voltage:3.7V

Super-thin Battery - HY 0144117 - 360mAh - 3.7V - Lithium Ion Battery - Rechargeable



Li-Ion 18650 Battery

Super-thin Battery - HY 0144117 - 360mAh - 3.7V - Lithium Ion Battery - Rechargeable

Super-thin Battery - HY 0144117 - 360mAh - 3.7V - Lithium Ion Battery

Super-thin Battery - 0144117 - 360mAh - 3.7V - Lithium Ion Battery - Rechargeable

Product Parameters

 No.

Item

General Parameter

Remark

1

Rated Capacity

Typical370mAh     Minimum360mAh

Standard discharge0.2C C5A) after Standard charge
2

Nominal Voltage

3.7V

Mean Operation Voltage

3

Voltage at end of Discharge

2.75V

Discharge Cut-off Voltage

4

Charging Voltage

4.2±0.03V
5

Internal Impedance

350mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times

6

Standard charge

Constant Current 0.2C5A

Constant Voltage 4.2V

0.01 C5A cut-off

Charge time : Approx 6h

7

Standard discharge

Constant current 0.2 C5A

end voltage 3.0V


8

Fast charge



Constant Current 0.5C5A

Constant Voltage 4.2V

0.01 C5A cut-off

Charge time : Approx 2.5h



9

Fast discharge

Constant current 0.5C5A

end voltage 3.0V


10

Maximum Continuous Charge Current

1.0 C5A
11

Maximum Continuous Discharge Current

1.0C5A
12

Operation Temperature Range

Charge:0~45℃

Discharge:-20~60℃

60±25%R.H.

Bare Cell

13

Storage Temperature Range

Less than 1 year: -20~25℃

less than 3 months: -20~40℃

60±25%R.H.

at the shipment stat

14

Pack  Dimension

      High: max31mm          Width: max23mm
Thickness
: max 4.2mm

Initial  Dimension
