Factory Mass Production Best Quality Hair Dryer Lipo Battery HY 603450-3S 1200mAh 11.1V Lithium Polymer Battery With UN38.3 Certification

$5.20
In stock
SKU
HY 603450-3S 1200mAh 11.1V

FOB Price: US $1.2 - 1.5 / Ampere
Min.Order Quantity: 1000 Ampere/
Please contact us for order li-ion battery !

    Place of Origin: Guangdong, China
    Brand Name: HY
    Model Number: 603450-3S
    Type: Li-polymer
    Nominal Voltage: 11.1V
    Size: 18*34*53mm
    Nominal Capacity: 1200mAh
    Product name: HY 603450-3S Li-ion Battery
    Warranty: 1 Year
    Weight: 68g
    Cycle life: 500 Times
    Application:  Hair Dryer Battery
    Certificate: UN38.3/CE/MSDS/ROHS
    Payment: Paypal.TT.Escrow.Western Union
    Max charge current: 1C


Li-Ion 18650 Battery

1200mAh 11.1V Hair Dryer Lithium Polymer Battery

603450-3S 1200mAh 11.1V Li-polymer Battery

Mass Production Best Quality 1200mAh Lipo Battery

Product Parameters

No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

1230mAh

Standard discharge(0.2C C5A) after Standard charge

Minimum

1200mAh

2

Nominal Voltage

11.1V

Mean Operation Voltage

3

Voltage at end of

9.0V

Discharge Cut-off Voltage

Discharge

4

Charging Voltage

12.6±0.03V



5

Internal Impedance

≤155mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times

6

Standard charge

Constant Current 0.2C5A

Charge time : Approx 6h

Constant Voltage 12.6V

0.01 C5A cut-off

7

Standard discharge

Constant current 0.2 C5A



end voltage 9.0V

8

Fast charge

Constant Current 0.5C5A

Charge time : Approx 2.5h

Constant Voltage 12.6V

0.01 C5A cut-off

9

Fast discharge

Constant current 0.5C5A



end voltage 9.0V



10

Maximum Continuous Charge Current

1 C5A



11

Maximum Continuous Discharge Current

1C5A



12

Operation Temperature Range

Charge: 0~45

60±25%R.H.

Bare Cell

Discharge: -20~60



13

Storage Temperature Range

Less than 1 year: -20~25

60±25%R.H.

less than 3 months: -20~40℃

at the shipment state

14

Pack  Dimension

High: max53mm

Width: max34mm
Thickness: max18mm

Initial  Dimension
